Desktop DAC/AMP Audeze Deckard



Giới thiệu Desktop DAC/AMP Audeze Deckard



---



DECKARD Class-A AMP/DAC Headphone Amplifier

If music is an important part of your life you deserve to hear the real thing. The Deckard is a powerhouse of a headphone amplifier combined with a high-performance DAC. There’s a front panel volume control and switches to choose gain and input so you can use the Deckard as a great line-level preamp to drive your whole desktop system. The sound is exciting and dynamic with beautifully rendered tonal colors that make music come alive.

"For price-to-performance ratio, it's a standout. Combines a highly resolving analog preamp with as little or as much gain as any sane person will need. Recommended? You bet!"







Exclusive DAC and amplifier technology

The DAC section has impressive specs and handles 16 to 32-bits and 44.1kHz to 384kHz sampling rates. The Deckard features a single-ended class-A output stage with good damping characteristics to control the strong and tuneful bass. Its power handling capabilities at lower impedances is ideal for planar magnetic headphones, but It drives any headphone with power to spare

Engineered and handcrafted in our California factory

The style and build quality is simply outstanding, the brushed aluminum finish and heft of the Deckard is substantial. The Deckard has input and gain settings with a smooth-turning volume control and puts out 4W of incredibly low-distortion sound for more air, separation and soundstaging abilities.





Cutting-edge industrial design by BMW’s i8 team

You’ll not only be proud of how the Deckard sounds, it also looks striking on the desktop with beautifully machined heatsinks down each side. Our strategic partner Designworks, a BMW group subsidiary, provided the industrial design for the Deckard.

Audeze combined their cutting-edge designs with our own circuit technologies to create an astonishingly accurate sounding headphone amplifier.







Thông số kỹ thuật amplifier headphone Audeze Deckard



---

Audeze 301-MA-3110-01 Specs



Line Out	Type Single-Ended Class-A SNR 106 dB A-weighted THD+N 0.00045% @ 1 kHz 2 VRMS A-weighted Frequency Response 20 Hz to 20 kHz (-0.03 dB at 20 Hz/-0.07 dB at 20 kHz) Impedance 50 ohm
Headphone Out	SNR 106 dB A-weighted THD+N 0.00045% @ 1 kHz 2 VRMS A-weighted Frequency Response 20 Hz to 20 kHz (-0.03 dB at 20 Hz/-0.07 dB at 20 kHz) Impedance 3 ohm Power Output 795 mW at 33 ohm 465 mW at 300 ohm 235 mW at 600 ohm
DAC	Resolution 16- to 32-bit Sample Rates 44.1 kHz 48 kHz 88.2 kHz 96 kHz 176.4 kHz 192.4 kHz 352.8 kHz 384 kHz (Mac only) Gain 0, 10, 20 dB
Power Requirements	100~120 VAC
System Requirements	Mac OS X 10.6.4 and above (native support) Windows XP, Vista, Windows 7, 8, 8.1 (requires USB2 driver installation)
Dimensions (WxDxH)	6.1 x 11.4 x 2" (155 x 290 x 50 mm)

Packaging Info

Package Weight	7.5 lb
Box Dimensions (LxWxH)	15.3 x 10.6 x 5.1"
